The NDS WR-P42-11 ZeroWire G2 Receiver is part of the ZeroWire G2 wireless surgical video transmission system, optimized for high-definition video delivery in operating room environments. This advanced receiver unit wirelessly receives uncompressed HD video from the paired ZeroWire G2 Transmitter, providing seamless connectivity and low-latency imaging on medical displays. It is FCC, T.U.V., and CE certified for safe use in patient vicinities.
Key Features:
- Wireless signal type: 60 GHz WIHD band (57–64 GHz)
- Video output: DVI (connects receiver to surgical/procedural display)
- Data rate: 0.952 to 3.807 Gb/s
- Maximum transmission range: Up to 30 ft (10 m), optimal at 8 ft (2.4 m); typical installed range 15 ft (5 m) or less
- System latency: Less than 1 frame (real-time, uncompressed HD video)
- Hardware encryption: 256-bit AES
- Auto-tracking and user feedback on link status
- Physical dimensions: 9.5 in x 3.5 in x 2.0 in (238 mm x 87.9 mm x 50 mm)
- Weight: 1.0 lb (0.45 kg), mounting base 0.8 lb (0.36 kg)
- Power: 100–240VAC input, 24V DC output, max 14W consumption
- Operating temperature: 32° to 104°F (0°–40°C)
- Humidity: 20%–90% RH, non-condensing
- Compatible only with ZeroWire G2 system components (WR-P42-11 Receiver + WT-P42-13 Transmitter)
