The NDS WT-P42-13 ZeroWire G2 Transmitter is a third-generation wireless medical video transmitter designed to deliver uncompressed HD video signals in surgical and endoscopy environments. This device allows for cable-free connectivity between endoscopic camera processors and video displays, enhancing ergonomics, safety, and clinical efficiency. The transmitter is typically paired with the ZeroWire G2 Receiver and is FCC, T.U.V., and CE certified for medical use.
Key Features:
- Supports: DVI and 3G-SDI/HD-SDI/SDI input
- Output: Wireless, 60 GHz (WIHD) with auto-tracking, AES 256-bit hardware encryption
- Maximum transmission distance: Up to 30 feet (10 meters), optimum at 8 feet (2.4 meters)
- Data rate: 0.952 to 3.807 Gb/s
- Low-latency (<1 frame), supports uncompressed HD video
- Power: 100–240VAC input, 24V DC output, max 14W consumption
- Physical dimensions (Tx or Rx): 9.5 in x 3.5 in x 2.0 in (238 mm x 87.9 mm x 50 mm)
- Weight: 1.0 lb (0.45 kg), base 0.8 lb (0.36 kg)
- Includes bonding button for secure transmitter–receiver pairing
- Works through some obstacles, though optimal with clear line-of-sight
- Designed for repeated sterilization and operation in OR environments
- Compatible only with ZeroWire G2 system components
